Kinze Grain Carts Rev. 4/14 - Manual (Page 23)

Jack Assembly
ITEM PART NO. QTY. DESCRIPTION
1 GA17051 1 Lower Leg
2 GD13598 1 Collar
3 GA9665 1 Thrust Bearing
4 G10840 1 Dowel Pin, ⅜" x 1¾"
5 GA17052 1 Top Leg
6 G10610- 2 Spring Pin, ⅜" x 2
7 GA17053 1 Gearbox
8 G10232 8 Lock Washer, 5⁄16"
9 G10043 8 Hex Head Cap Screw, 5⁄16"-18 x ¾"
10 GD13604 3 Bushing
11 G11032 3 Bushing, 1½" O.D. x 1.015 I.D.
12 GD13605 1 Output Spur Gear
13 GD13608 1 Output Shaft
14 G11031 2 Spring Pin, 5⁄16" x 1½"
15 GD13606 1 Input Spur Gear
16 GD13600 2 Thrust Washer
17 GD13601 1 Bevel Gear
18 GD13602 1 Output Cluster Gear
19 GD13698 1 Input Shaft
20 GA14992 1 Shifter Housing
21 GD13635 1 Cap
22 G10960 4 Hex Non-Serrated Flange Cap Screw, ¼"-20 x ⅝", Grade 5
23 GD13609 1 Detent Ball
24 GD13610 1 Detent Spring
25 GD13603 1 Output Shaft
26 G11030 1 Spring Pin, ⅜" x 1¾"
A GA17044 - Jack Complete (Items 1-26)
