Hydraulic Flow Gate (1100)
ITEM PART NO. QTY. DESCRIPTION
1 --- 1 See “Hydraulic Flow Gate, Rear Assembly (1100)” on page P65
2 --- 1 See “Hydraulic Flow Gate, Front Assembly (1100)” on page P63
3 G11124 40 Hex Serrated Flange Cap Screw, ⅜"-16 x 1"
4 G10636 10 Carriage Bolt, ½"-13 x 1½"
5 G10111 14 Lock Nut, ½"-13
6 GA9705 1 Restrictor Elbow
7 G11389 8 Flat Washer, ½" Plated SAE
8 GA16616 1 Top Axle Cover
9 GA16615 1 Rear Axle Cover
10 GA16614 1 Front Axle Cover
11 GA16188 1 Lower Axle Cover
12 GD25306 2 Clamp Collar, 2"
13 G11409 4 Hex Serrated Flanged Cap Screw, ¼"-20 x 1"
14 G10110 4 Lock Nut, ¼"-20, Grade B
15 G10657 4 Hex Head Cap Screw, ½"-13 x 1¾", Grade 8
