Electric Roll Tarp (2013 Production and on)
ITEM PART NO. QTY. DESCRIPTION
1 G10936
G11386
G10109 1
1
1 Hex Head Cap Screw, 5⁄16"-18 x 3½"
Flat Washer, 5⁄16" SAE
Lock Nut, 5⁄16"-18
2 G10430 1 External Retaining Ring, 1¼"
3 G11484 1 Flat Washer
4 GD27043 2 Dome Plug
5 GD27042 2 Cap Plug W/Hole
6 GD23856 4 Spiral Torsion Spring
7 GD24094 2 Spacer Washer
8 G10004
G11387
G10229
G10101 4
4
4
4 Hex Head Cap Screw, ⅜"-16 x 1¼"
Flat Washer, ⅜" SAE
Lock Washer, ⅜"
Hex Nut, ⅜"-16
9 GD27095
G10985
G10003
G10229
G10101 1
2
2
4
4 Pivot Bracket
Hex Washer Head Cap Screw, ⅜"-16 x 1"
Hex Head Cap Screw, ⅜"-16 x 1½"
Lock Washer, ⅜"
Hex Nut, ⅜"-16
10 GA16460 1 Pivot Pin
11 GD27081
G10985
G10229
G10101 1
2
2
2 Crank Retainer Bracket
Hex Washer Head Cap Screw, ⅜"-16 x 1"
Lock Washer, ⅜"
Hex Nut, ⅜"-16
12 GD27082
G10985
G10229
G10101 2
2
2
2 Crank Support Bar
Hex Washer Head Cap Screw, ⅜"-16 x 1"
Lock Washer, ⅜"
Hex Nut, ⅜"-16
13 GA18840 1 Durabilt Motor, 3⅛" Shaft
14 G10108 2 Lock Nut, ⅜"-16
15 G10049 1 Hex Head Cap Screw, 3⅜"-16 x 2½"
16 G10041 1 Hex Head Cap Screw, 5⁄16"-18 x 2"
17 GA18833 1 Motor Adapter
18 GD23852
G10985
G10229
G10101 3
6
6
6 Roll Tube Deflector
Hex Washer Head Cap Screw, ⅜"-16 x 1"
Lock Washer, ⅜"
Hex Nut, ⅜"-16
19 GA16448 1 Roll Tube
20 GA18835 1 Upper Flex Arm
21 GD23855 1 Flex Arm Joint
22 GA18836 1 Lower Flex Arm
23 GA16779 1 Wireless Receiver
24 GD24041 1 Receiver Mount
25 GD27037 1 Motor Mount Bracket
26 GD27038
G10622 2
2 Upper Arm Spacer
Serrated Flange Nut, ⅜"-16
27 G10043
G10232 3
3 Hex Head Cap Screw, 5⁄16"-18 x ¾"
Lock Washer, 5⁄16"
28 GD27039 2 Bellow Plate
29 GD27041 2 Bellow Plate
30 GD27044 1 Bellow Rubber Arm
31 GD27100 2 Flexible Arm Joint End Cap
32 G10902
G10620 4
4 Carriage Bolt, 5/16"-18 x 2½"
Serrated Flange Nut, 5/16"-18
