Kinze Grain Carts Rev. 4/14 - Manual (Page 133)

Auger Rotate Cylinder
ITEM PART NO. QTY. DESCRIPTION
1 A16132 1 Barrell (Non-Stock Item)
2 GD16202 1 Rod
3 GD16200 1 Piston
4 GD27235 1 Nylon Lock Nut, 1"-14, Grade 8
5 *D12050 2 Piston Ring, 3"
6 *D12051 1 Piston Seal, 3"
7 *D12209 1 Energizer Seal, 3"
8 *D12208 1 O-Ring, No. 214
9 GD11984 1 Gland
10 *D12202 1 O-Ring, No. 334
11 *D12203 1 Back-Up Ring
12 *D12253 1 U-Cup
13 *D12200 1 Wiper, 1¾"
14 *D12104 1 Ring
15 GA8130
GR1401
G10939
G10101 1
-
-
-
Clevis W/Bushings, Hex Head Cap Screw And Hex Nut
Bushing
Hex Head Cap Screw, ⅜"-16 x 2¼"
Hex Nut, ⅜"-16
16 GD23404 1 Block
17 GD12239 1 O-Ring, No. 016
18 GA13965 1 Bi-Directional Flow Control
19 GA8882
GR1517 1
-
Counter Balance Valve
Seal Kit For Counter Balance Valve, Includes: (3) O-Rings, (3) BU Rings
20 G6408-06
GR1045 3
-
Plug W/O-Ring, 9⁄16"-18 O-Ring
O-Ring
21 G6400-06
GR1045 2
-
Connector W/O-Ring, 9⁄16"-18 Male JIC To O-Ring
O-Ring
22 G10932 2 Hex Socket Head Cap Screw, 5⁄16"-18 x 2", Grade 8
23 GA16133 1 Hydraulic Steel Tube, ⅜"
A GA16134 - Cylinder Complete, 3" x 10" (Part Number Stamped On Barrel) W/Block
B GR1740 1 Seal Kit, Includes: (1) Wiper, (1) U-Cup, (2) O-Rings, (1) BU Ring, (2) Cast Iron
Rings, (1) Seal, (1) Energizer
*Item is part of seal kit, item can not be purchased individually.
Grain Cart M0238-02
Rev. 4/14 P130
