P112 – Kinze Grain Carts Rev. 4/14 User Manual
Page 115
Row Crop Axle (1100/1300)
ITEM
PART NO.
QTY.
DESCRIPTION
7
G10027
12/16
Hex Head Cap Screw, ¾"-10 x 2½"
8
GA17045
2
Solid Axle Pin
9
GD1109
4
Bushing, 41⁄64" I.D. x ⅞" O.D. x ¼" Long
10
G10230
4
Lock Washer, ⅝"
11
G10055
4
Hex Head Cap Screw, ⅝"-11 x 1¼"
12
GA14475
2
Top Load Cell
13
G11389
2
Flat Washer, ½" Plated SAE
14
GD24853
2
Load Cell Blank
15
GA16995
4
Top Arm Support Link
16
G10234
38
Machine Bushing, 2⅛", 10 Gauge (.1345")
17
G10336
38
Machine Bushing, 2⅛", 14 Gauge (.0747")
18
G11393
8
Flat Washer, ⅞"
19
G11041
8
Hex Head Cap Screw, ⅞"-9 x 12"
20
GD13626
8
Eyebolt, 1¼"-7 x 6⅝"
21
G10330
8
Lock Washer, ⅞"
22
G10955
8
Hex Nut, ⅞"-9
23
GA18842
2
Outer Link Plate
24
GA15643
G10400
G10112
4
4
4
See “Hub Assembly (Row Crop Without Electronic Scale Package)” on page P120
Hex Head Cap Screw, ¾9-10 x 6½"
Lock Nut, ¾"-10
25
G10400
4
Hex Head Cap Screw, ¾"-10 x 6½"
G10112
4
Lock Nut, ¾"-10
26
GD14436
G10641
G11093
8
8
16
Pin, 2⅛" x 15⅜"
Grease Fitting, ⅛" NPT
External Retaining Ring, 2⅛"
27
GD14437
G10641
G11093
4
8
8
Pin, 2⅛" x 35⅞"
Grease Fitting, ⅛" NPT
External Retaining Ring, 2⅛"
28
GA17091
2
Bottom Arm Link
29
G10236
8
Lock Washer, 1¼"
30
G10239
8
Hex Nut, 1¼"-7
31
---
-
See “Tire Assemblies (Row Crop)” on page P122
32
G10107
8
Lock Nut, ⅝"-11
33
G10156
4
Hex Head Cap Screw, ¾"-10 x 1¼"
34
G10231
4
Lock Washer, ¾"
35
GD9592
4
Special Washer
36
G10404
8
Machine Bushing, 3⅛" x 2⅛" x 3⁄16"
37
GA17306
1
Row Crop Front Axle
38
GA17394
GA17395
2
-
Rear Axle Mount, 1300 (Shown)
Rear Axle Mount, 1100
39
G10037
2
Hex Head Cap Screw, ½"-13 x 1¼"
40
GD23996
8
Load Cell Shim, 10 Gauge (.1345") (As Required)
41
GD25149
8
Load Cell Shim, 16 Gauge (.0598") (As Required)
42
GA17396
GA17045
2
2
Solid Axle Pin (2013 Production and on)
Solid Axle Pin (2012 Production)
43
GA17294
2
Row Crop Axle
44
GA18843
2
Inner Link Plate
45
GA17293
G10543
G11392
G10112
4
16
32
16
Row Crop Axle Sleeve
Hex Head Cap Screw, ¾"-10 x 3", Full Thread
Flat Washer, ¾" SAE
Lock Nut, ¾"-10
Grain Cart
M0238-02
Rev. 4/13
