Kinze Grain Carts Rev. 4/14 - Manual (Page 45)

Frame Assembly (1100/1300 Row Crop)
ITEM PART NO. QTY. DESCRIPTION
1 GA17973
G10004
G11091
GD26441-01 1
-
Upper Bolt Plate
Hex Head Cap Screw, ⅜"-16 x 1¼"
Serrated Flange Nut, ⅜"-16
Grain Transfer Weather Strip, 22"
2 GA15984
GA16196 1
1 Horizontal Auger (1300)
Horizontal Auger (1100)
3 G10017
G10111 10
10 Hex Head Cap Screw, ½"-13 x 1½"
Lock Nut, ½"-13
4 GD23893 1 Auger Shim
5 GA17154 1 Cleanout
6 GA15991 1 See “Horizontal Auger Drive Hub Assembly” on page P12
7 GD23343 1 Horizontal Auger Rear Cover
8 GR0270 6 Lug Bolt, 9⁄16"-18
9 GD24835 1 Upper SMV Bracket
10 G11413 10 Hex Socket Flange Cap Screw, ½"-13 x 1", Grade 5
11 GD24836 1 Lower SMV Bracket
12 GD13805 1 Slide Pan Nut
13 GD13804 1 Slide Pan Washer
14 G10163 2 Wing Nut, ⅜"-16
15 GD23483 1 Storage Cover Plate
16 GD24494
G10465 1 Rear Hinge Pin
Cotter Pin, ¼" x 1¼"
17 GA16053
GA16405 1 Cleanout Push Rod (1300)
Cleanout Push Rod (1100)
18 G10037
G11389
G10228 1
1
1 Hex Head Cap Screw, ½"-13 X 1¼"
Flat Washer, ½" Plated SAE
Lock Washer, ½"
19 GA16726
G10305
G11091 1
-
-
Rear Cleanout Door
Carriage Bolt, ⅜"-16 x 1"
Serrated Flange Nut, ⅜"-16
20 GA16054
GA16403
G11051 2
1
1 Cleanout Push Rod Assembly (1300)
Cleanout Push Rod Assembly, (1100)
Hex Socket Set Screw, ½"-13 x 2"
21 GA16976
GA16978 1
1 Frame (1300)
Frame (1100)
22 GD22750
G10465 1 Hinge Pin (1300)
Cotter Pin, ¼" x 1¼" (1300)
23 GA16056
G10305
G11091 1
-
-
Front Cleanout Door (1300)
Carriage Bolt, ⅜"-16 x 1" (1300)
Serrated Flange Nut, ⅜"-16 (1300)
24 G10027
G11392
G10112 24
48
24 Hex Head Cap Screw, ¾"-10 x 2½"
Flat Washer, ¾" SAE
Lock Nut, ¾"-10
25 GD26430
G10004
G11091
GD26442-03 1
-
Lower Filler Bolt Plate
Hex Head Cap Screw, ⅜"-16 x 1¼"
Serrated Flange Nut, ⅜"-16
Grain Transfer Weather Strip, 19"
26 GD26428
G10004
G11091
GD26442-02 2
-
Side Filler Bolt Plate
Hex Head Cap Screw, ⅜"-16 x 1¼"
Serrated Flange Nut, ⅜"-16
Grain Transfer Weather Strip, 20½"
27 GA15936 1 Inner Grain Transfer
28 GD26432
G10004
G11091
GD26442-01 2
-
-
-
Bolt Plate
Hex Head Cap Screw, ⅜"-16 x 1¼"
Serrated Flange Nut, ⅜"-16
Grain Transfer Weather Strip, 3¾"
