Decals, paint, and miscellaneous, Notice, Rev. 4/13 – Kinze Grain Carts Rev. 4/14 User Manual
Page 162
Part No.: G7100-464
Description: Handheld Control Label
WEEKLY
7100-110
Part No.: G7100-110
Description: Decal, Grease Weekly
ANNUALLY
7100-277
Part No.: G7100-277
Description: Decal, Grease Annually
7100-116
DAILY
Part No.: G7100-116
Description: Decal, Grease Daily
Part No.: G7100-314
Description: Decal, Torque Value
7100-346
NOTICE
KEEP TARP AT 40-60 LB (18-27 KG) TENSION TO PREVENT EXCESS WEAR.
TARP MUST BE IN THE OPEN POSITION BEFORE UNLOADING OR LOADING.
DO NOT WALK OR STAND ON END CAPS TO PREVENT DAMAGE.
OPEN TARP SYSTEM AND SECURE ROLL TUBE TO WAGON FOR SPEEDS
OF 30 MPH (48 KPH) OR HIGHER TO PREVENT DAMAGE.
OPERATING INSTRUCTIONS
1. CRANK TARP UP
UNDER PLATE
2. BRING CRANK DOWN
3. LIFT (40-60 LBS)
CRANK INTO RETAINER
TO ADJUST TENSION:
1. ROLL TARP DOWN FROM
LATCH PLATE.
FROM SHAFT.
3. ROTATE CRANK ONE OR
REASSEMBLE.
Part No.: G7100-346
Description: Decal, Notice
Part No.: G7100-130
Description: Decal, Electronic Scale
Part No.: GD1512
Description: Cable Tie, 7½"
Part No.: GD2117
Description: Cable Tie, 14½"
Decals, Paint, and Miscellaneous
TM
M0238-02
Grain Cart
P159
Rev. 4/13
