ITEM PART NO. QTY. DESCRIPTION
1 GA17106
G10004
G11091 1
7
7 Upper Bolt Plate
Hex Head Cap Screw, ⅜"-16 x 1¼"
Serrated Flange Nut, ⅜"-16
2 GA16190 1 Horizontal Auger
3 G10017
G10111 10
10 Hex Head Cap Screw, ½"-13 x 1½"
Lock Nut, ½"-13
4 GD23893 1 Auger Shim
5 GB0359 1 Cleanout
6 GA15991 1 See “Horizontal Auger Drive Hub Assembly” on page P12
7 GD24866
GD17332 1
1 Rear Horizontal Auger Cover
Hex Socket Set Screw, ½"-13 x 3"
8 GR0270 6 Lug Bolt, 9⁄16"-18
9 GD24961 2 SMV Bracket
10 G11413 10 Hex Socket Flange Cap Screw, ½"-13 x 1", Grade 5
11 GD13805 1 Slide Pan Nut
12 GD13804 1 Slide Pan Washer
13 G10163 2 Wing Nut, ⅜"-16
14 GD23483 1 Storage Cover Plate
15 GA17104
G11051 2
1 Cleanout Push Rod Assembly
Hex Socket Set Screw, ½"-13 x 2"
16 GA17103 1 Cleanout Push Rod
17 GD24494
G10465 1
2 Rear Hinge Pin
Cotter Pin, ¼" x 1¼"
18 G10037
G11389
G10228 1
1
1 Hex Head Cap Screw, ½"-13 x 1¼"
Flat Washer, ½" Plated SAE
Lock Washer, ½"
19 GA17096
G10305
G11091 1
3
3 Clean Out Door
Carriage Bolt, ⅜"-16 x 1"
Serrated Flange Nut, ⅜"-16
20 GA17093 1 Frame
21 GD24889
G10004
G11091 1
5
5 Lower Filler Bolt Plate
Hex Head Cap Screw, ⅜"-16 x 1¼"
Serrated Flange Nut, ⅜"-16
22 G10027
G11392
G10112 20
40
20 Hex Head Cap Screw, ¾"-10 x 2½"
Flat Washer, ¾" SAE
Lock Nut, ¾"-10
23 GA16254 1 Rear Inner Transfer Assembly
24 GD24888
G10004
G11091 2
10
10
Side Filler Bolt Plate
Hex Head Cap Screw, ⅜"-16 x 1¼"
Serrated Flange Nut, ⅜"-16
25 GD21843
G10004
G11091 2
4
4 Bolt Plate
Hex Head Cap Screw, ⅜"-16 x 1¼"
Serrated Flange Nut, ⅜"-16
26 G11286 4 Hex Socket Button Head Cap Screw, ⅜"-16 x ¾", Grade 8
27 GD21874 4 Retainer Wear Pad
28 GD21835 2 Rotate Wear Pad
Frame Assembly (900)
Grain Cart M0238-02
Rev. 4/13 P38
