Kinze Grain Carts Rev. 4/14 - Manual (Page 61)

Hydraulic Flow Gate, Front Assembly (900)
ITEM PART NO. QTY. DESCRIPTION
1 GA17139 1 Front Tunnel
2 GB0218 8 Bushing, 21⁄32" I.D. x ⅞" O.D. x 19⁄32" Long
3 G11391 32 Flat Washer, ⅝" SAE
4 G10005 8 Hex Head Cap Screw, ⅝"-11 x 1¾"
5 GD24936 8 Door Linkage Plate
7 GA16319 4 Crank Arm
8 G10108 11 Lock Nut, ⅜"-16
9 G10809 11 Hex Head Cap Screw, ⅜"-16 x 3¼"
10 GA16625 1 Sight Gauge Link
11 G11510 2 Locknut, ⅝"-11, Grade 8
12 G11509 2 Hex Head Cap Screw, ⅝"-11 x 4½", Grade 8
13 GA17242 1 Cylinder Crank Arm
14 GD23679 1 Locating Ring, 2"
15 GD24949 1 Front Torque Tube
16 G10107 16 Lock Nut, ⅝"-11
17 GB0654
GA17143 4
2 Bushing
Crank Tube Support
18 G10008 8 Hex Head Cap Screw, ⅝"-11 x 2"
19 GB0672 4 Bushing
20 GA17629 1 See “Hydraulic Flow Gate Cylinder” on page P126
21 G11394 4 Flat Washer, 1" SAE
22 GR0375
GR0193 1
2 Pin, 1" x 3½"
Hair Pin Clip
23 GR0962
GR0193 1
2 Pin, 1" x 3⅜"
Hair Pin Clip
24 GA17136 2 Front Door
25 GA17138 1 Front Flow Gate
26 GA17137 1 Front Flow Gate (Opposite Side)
Grain Cart M0238-02
Rev. 4/13 P58
