Hydraulic Flow Gate, Front Assembly (1500)
ITEM
PART NO.
QTY.
DESCRIPTION
1
GA16938
1
Front Tunnel
2
GA16911
1
Front Rear Door
3
GA17038
1
Mid Front Flow Gate
4
GA16912
1
Front Rear Door (Opposite Side)
5
GA17039
1
Mid Front Flow Gate (Opposite Side)
6
G10108
17
Lock Nut, ⅜"-16
7
GA16318
2
Crank Tube Support
8
GA20093
1
Front Torque Tube (1500)
9
GD23672
14
Door Linkage Plate
10
GA16319
7
Crank Arm
11
GA17242
1
Cylinder Crank Arm
12
GA17237
1
See “Hydraulic Flow Gate Cylinder” on page P126
13
GD23679
1
Locating Ring, 2"
14
GA16625
1
Sight Gauge Link
15
GD23979
1
Tube Cover Plate
16
G10107
27
Lock Nut, ⅝"-11
17
G11391
54
Flat Washer, ⅝" SAE
18
GB0218
16
Bushing, 21⁄32" I.D. x ⅞" O.D. x 19⁄32" Long
19
G10008
27
Hex Head Cap Screw, ⅝"-11 x 2"
20
GB0654
7
Bushing
21
GB0672
4
Bushing
22
G10809
17
Hex Head Cap Screw, ⅜"-16 x 3¼"
23
G11394
4
Flat Washer, 1" SAE
24
GR0962
1
Pin, 1" x 3⅜"
25
GR0193
4
Hair Pin Clip
26
GA17169
1
Front Door Panel
27
GA17170
1
Front Door Panel (Opposite Side)
28
GA17076
1
Tube Support
29
G11509
2
Hex Head Cap Screw, ⅝"-11 x 4½", Grade 8
30
G11510
2
Locknut, ⅝"-11, Grade 8
31
GR0375
1
Pin, 1" x 3½"
32
GD24118
1
Indicator Actuator
33
GA16624
1
Sight Gauge Link
