Kinze Grain Carts Rev. 4/14 - Manual (Page 69)

Hydraulic Flow Gate, Rear Assembly (1100)
ITEM PART NO. QTY. DESCRIPTION
1 GA16671 1 Rear Flow Gate Tunnel
2 GA16318 3 Crank Tube Support
3 GA16861
GA16732 1
-
Front Rear Flow Gate (Row Crop and Flotation) (Shown)
Front Rear Flow Gate (Track)
4 GA16772 1 Rear Flow Gate
5 GA16773 1 Rear Flow Gate (Opposite side)
6 GA16855
GA16731 1
-
Mid Front Flow Gate (Row Crop and Flotation) (Shown) (Opposite Side)
Front Rear Gate (Track) (Opposite Side)
7 GA16319 4 Crank Arm
8 GD23672 8 Door Linkage Plate
9 GA20090 1 Rear Torque Tube (1100)
10 GD23679 1 Locating Ring, 2"
11 G10809 9 Hex Head Cap Screw, ⅜"-16 x 3¼"
12 G10108 17 Lock Nut, ⅜"-16
13 GA18554 2 Rear Safety Grate
14 G11391 36 Flat Washer, ⅝" SAE
15 G10107 24 Lock Nut, ⅝"-11
16 GB0218 8 Bushing, 21⁄32" I.D. x ⅞" O.D. x 19⁄32" Long
17 G10008 24 Hex Head Cap Screw, ⅝"-11 x 2"
18 GB0654 4 Bushing
19 GB0672 6 Bushing
20 GD24011 2 L.H. Safety Screen Bracket
21 G11387 8 Flat Washer, ⅜" SAE
22 GD23979 1 Tube Cover Plate
23 GD24014 2 R.H. Safety Screen Bracket
24 G10003 8 Hex Head Cap Screw, ⅜"-16 x 1½"
Grain Cart M0238-02
Rev. 4/14 P66
