Lower Tank Assembly (1500)
ITEM PART NO. QTY. DESCRIPTION
1 G10027
G11392 8
8 Hex Head Cap Screw, ¾"-10 x 2½"
Flat Washer, ¾" SAE
2 G10112 8 Lock Nut, ¾"-10
3 GA16815 1 Inner Truss Support, 1500
3 GA16022 1 Front Tank Corner
4 GA16814 1 Inner Truss Support, 1500
5 G10017 18 Hex Head Cap Screw, ½"-13 x 1½"
6 G10071 4 Serrated Flange Nut, ½"-13
7 GA16498 1 Lower Tank Side (1500 Flotation)
8 GA16030 1 Rear Tank Corner
9 G11091 80 Serrated Flange Nut, ⅜"-16
10 G10599 80 Carriage Bolt, ⅜"-16 x 1 ¼"
11 GA16029 1 Rear Tank Corner
12 GA16497 1 Lower Tank Side (1500 Flotation)
13 GA16021 1 Front Corner Tank
14 G10111 28 Lock Nut, ½"-13
15 GD25773 2 Lower Clamp Plate
16 --- - ---
17 GD24928
GD24927 1
1 Adjustable Tank Flange Plate, R.H.
Adjustable Tank Flange Plate, L.H.
18 G10599
G11091 4
4 Carriage Bolt, ⅜"-16 x 1¼"
Serrated Flange Nut, ⅜"-16
19 GD24970
GD24971 1
1 R.H. Rear Inner Cover
L.H. Rear Inner Cover
