71
10 Appendix
Housing
Interface
Approvals/approval marks
Housing type Plastic housing for panel mounting acc. to IEC 61554
Depth behind panel 90mm
Ambient/storage
temperature range 0 to 55°C / -30 to +70°C
Climatic conditions rel. humidity
≤
90% annual average, no condensation
Operating position horizontal
Enclosure protection acc. to EN 60529, front IP 65, back IP 20
Weight (fully equipped) approx. 380g
Modbus
Interface type
RS422/RS485
Protocol Modbus, Modbus-integer
Baud rate 9600, 19200, 38400
Device address 0—255
Max. number of
nodes 32
PROFIBUS-DP
Device address
0—255
Approval mark Testing agency Certificate/
certification
number
Test basis valid for
c UL us Underwriters
Laboratories E 201387 UL 61010-1
CAN/CSA-C22.2
No. 61010-1
JUMO di 308
Type 701550/...
