10 Appendix
10.1 Technical data
Thermocouple input
1
incl. measuring accuracy at the cold junction
2
in the range from 300…1820°C
RTD temperature probe input
3
The accuracy refers to the max. measurement range span. The linearization accuracy is
reduced with short spans.
Designation Measuring range Measuring
accuracy
1,3
Ambient
temperature
error
Fe-Con „L“
Fe-Con „J“
Cu-Con „U“
Cu-Con „T“
NiCr-Ni „K“
NiCr-Con „E“
NiCrSi-NiSi „N“
Pt10Rh-Pt „S“
Pt13Rh-Pt „R“
Pt30Rh-Pt6Rh „B“
W5Re-W26Re „C“
W3Re-W25Re „D“
W3Re-W26Re
Chromel-Copel
EN 60584
EN 60584
EN 60584
EN 60584
EN 60584
EN 60584
EN 60584
EN 60584
GOST R
8.585-2001
-200 to +900°C
-200 to +1200°C
-200 to
+600°C
-200 to +400°C
-200 to +1372°C
-200 to +1000°C
-100 to +1300°C
0 to +1768°C
0 to +1768°C
0 to +1820°C
0 to +2320°C
0 to +2495°C
0 to +2400°C
-200 to
+800°C
≤
0.25%
≤
0.25%
≤
0.25%
≤
0.25%
≤
0.25%
≤
0.25%
≤
0.25%
≤
0.25%
≤
0.25%
≤
0.25%
2
≤
0.25%
≤
0.25%
≤
0.25%
≤
0.25%
100ppm/K
100ppm/K
100ppm/K
100ppm/K
100ppm/K
100ppm/K
100ppm/K
100ppm/K
100ppm/K
100ppm/K
100ppm/K
100ppm/K
100ppm/K
100ppm/K
Cold junction Pt 100 internal
Designation Connection
circuit Measuring
range Measuring
accuracy
3
Ambient
tempera-
ture error
3-/4-
wire 2-
wire
Pt100 DIN EN
60751 2-wire/3-wire/
4-wire -200 to +850°C
≤
0.05%
≤
0.4% 50ppm/K
Pt500 DIN EN
60751 2-wire/3-wire/
4-wire -200 to +850°C
≤
0.2%
≤
0.4% 100ppm/K
Pt1000 DIN EN
60751
2-wire/3-wire/
4-wire -200 to +850°C
≤
0.1%
≤
0.2% 50ppm/K
Pt50 GOST
6651-94 2-wire/3-wire/
4-wire -200 to +850°C
≤
0.1%
≤
0.8% 50ppm/K
Pt100 GOST
6651-94 2-wire/3-wire/
4-wire -200 to +850°C
≤
0.05%
≤
0.4% 50ppm/K
Cu50 GOST
6651-94 2-wire/3-wire/
4-wire -50 to +200°C
≤
0.2%
≤
1.6% 50ppm/K
Cu100 GOST
6651-94 2-wire/3-wire/
4-wire -50 to +200°C
≤
0.1%
≤
0.8% 50ppm/K
KTY11-6 2-wire -50 to +150°C
− ≤
2.0% 50ppm/K
