51
7 Configuration
7.3 Outputs „OUTPUT“
Configuration of the instrument outputs is subdivided
into analog outputs (OUTANALG; max. 2) and binary
outputs (OUTLOGIC; max. 10). Binary outputs are
relays, solid-state relays and logic outputs. Display
and numbering of the outputs depends on the
assignment of the option slots.
The switching states of the binary outputs 1...4 are
shown in the display (K1…K4).
Numbering of
the outputs
Standard for all instrument versions:
(Binary) output 1 = relay
(Binary) output 2 = relay
(Binary) output 3 = logic output
(Binary) output 4 = logic output
Extended numbering of the option slots:
Configuration
Analog inputs
Limit
comparators
Outputs
Binary
functions
Display /
Operation
Interfaces
Option
slot Plug-in
board with
1 analog
output Plug-in
board with
1 binary
output
(relay or
solid-state
relay) Plug-in
board with
2 binary
outputs
(2 relays)
Option
1 Output 5 Output 5 Output 5+8
Option
2 Output 6 Output 6 Output 6+9
Option
3 Output 7 Output 7 Output 7+10
