59
7 Configuration
Bargraph
scaling (Setup) -19999
... 0 ...
+99999
-19999
...100...
+99999
Scaling start
Scaling end
Adjustment only possible in the setup
program:
-> Display/Operation -> Display > Lower
display
Channel name (Setup) INPUT1
INPUT2
MATHE1
MATHE2
xxxx
xxx.x
xx.xx
x.xxx
System
point
Channel name for analog input 1
Channel name for analog input 2
Channel name for math 1
Channel name for math 2
no digit after the decimal point
one digit after the decimal point
two digits after the decimal point
three digits after the decimal point
Digit after the decimal point as system
point
Individual channel names (max. 8 characters)
can be allocated for the analog inputs and
math functions.
The decimal point of the values of the analog
inputs can be defined different to that of the
system point.
Adjustment only possible in the setup
program:
-> Display/Operation -> Display > Channel
name
(The setting at the instrument is made in the
menu for analog input, parameter
„DECPOINT“.)
User data (Setup) A maximum of eight parameters from the
configuration level can be defined to be
available in the user level of the instrument.
The parameter name (max. 8 characters) can
be user-defined. Without a user-defined entry,
the name programmed in the instrument will
appear.
Adjustment only possible in the setup
program:
-> Display/Operation -> User data
Parameter Value/
Selection
Description
Factory settings are shown bold.
