INFICON XTM/2 Thin Film Deposition Monitor - Manual (Page 36)

2 - 10
IP
N 07
4-
18
6S
XTM/2 Operating Manual
9—
Access to adjust LCD contrast, see section 6.1 on page 6-1 .
10—
Enter and cursor down. Two function switch used when the display is in the
program mode.
11— DIGITS (0-9)
Decimal based key pad for data entry.
a. If the zero key is held down during power-up, the communications
interface may be configured (see section 3.8.1 on page 3-16 )
b. If the nine key is held down during power-up, all of the LCD segments
will remain lit until the key is released, see Figure 2-7 on page 2-11 .
12—
Clear and cursor up. Two function switch that is used when the display is
in the program mode.
13—
Optional mounting kit, (IPN 757-212-G1) for mounting one unit in full rack
or (757-212-G2) for mounting two units side by side in full rack.
