73
SECTION 11: TEST MODE
The Test Mode permits turning on and off the instrument outputs in order to determine
proper operation.
To enter the Test Mode from Base Mode:
1. Press the MODE key until Test appears in the message display.
2. Press the SCROLL key to enter the Test Mode.
To return to Base Mode:
1. Press the MODE key until Basemode appears in the message display.
2. Press the SCROLL key to return to Base Mode.
Exiting the Test Mode will turn all outputs off and terminate communications. Control of
outputs and communications will be returned to the mode from which access to the
Test Mode was gained.
Press the SCROLL key to step through the parameters. Use the UP and DOWN keys
to change the parameter setting.
Table 11-1 Test Mode Parameters
Step Display Setting
1 Output1
2
On/Off
2 Output2
1,2
On/Off
3 Output3
1,2
On/Off
4 EOPrelay On/Off
5 Event1
1
On/Off
6 Event2
1
On/Off
7 Event3
1
On/Off
8 Event4
1
On/Off
9 Comms Send/Stop
NOTES:
1. Only appears if presence has been registered in Hardware Define (Configuration
Mode)
2. Driven to 100% when turned on.
