Notes on Configuration Mode Parameters
1. If the secondary output is chosen as Output 2 (COOL) control output, its action is
always the compliment of the action of Output 1.
2. The default setting for Output 2 Usage is Alarm 2 hardware output, direct-acting (if
relay/SSR output) or Output 2 - COOL (if DC output).
3. The default setting for Output 3 Usage is Alarm 1 hardware output, direct-acting (if
relay/SSR output) or Process Variable Recorder Output (if DC output)
4. This parameter does not appear in the sequence if the input type selected is not
thermocouple. If the CJC is disabled, the initial display in Operator Mode will show
horizontal bars flashing in the lower display.
5. The primary input default setting is dependent upon the hardware fitted, as indicated
in the Hardware Definition Code.
6. These parameters do not appear if the Hardware Definition Comms parameters is
set to none.
7. This parameter does not appear if the Programmer communications option is set to
operate in Master mode.
8. Internal software prevents (a) the Setpoint High Limit being given a value less than
any setpoint value contained in currently-resident programs, and (b) the Setpoint
Low Limit being given a value greater than any setpoint value contained in currently-
resident programs.
9. These parameters are applicable only if a linear input is fitted.
10. These parameters do not appear if features are not fitted.
