SECTION 9: ENABLE MODE
The Enable mode controls which modes are readily available to the operator. If a mode
is disabled or off, it will not be displayed when the MODE key is pressed in Base Mode.
If a mode is set to Read Only, that mode is not available to be changed by the operator,
such as the Setpoint Change and AutoTune settings.
To enter the Enable Mode from Base Mode:
1. Press the MODE key until Enable appears in the message display.
2. Press and hold the SCROLL key for five seconds to access the Enable Mode.
3. With PassCode displayed in the message display, use the UP and DOWN keys to
set the pass code in the numerical display.
4. With the proper pass code displayed, press the SCROLL key.
If a proper pass code has been entered, the control will enter the Enable Mode, with
EnAb shown in the lower display. If an improper pass code has been entered, the
control will revert back to the Enable prompt.
Once the Enable Mode has been accessed, if no key is pressed for more than one
minute, the instrument will automatically revert to Base Mode.
Press the SCROLL key to step through the parameters. Press the UP and DOWN keys
to change the parameter setting.
Table 9-1
Enable Mode Parameters
STEP
MODE
DISPLAY
AVAILABLE
SETTINGS
1
Profile Parameters
Prof Par
Enable
Disable
2
Setpoint Change (Change setpoint in Base Mode)
Setpoint
Enable
Read Only (R/O)
3
Pre-Tune Facility
PreTune
Enable
Read Only (R/O)
Off
4
Auto-Tune Facility
AutoTune
Enable
Read Only (R/O)
Off
5
Alarm Parameters
Alarm
Enable
Disable
6
Tuning Parameters
TunePar
Enable
Disable
7
Configuration Parameters
ConfPar
Enable
Disable
