10.3 Configuration Mode Parameters
The Configuration Mode parameters are presented for view/edit in the following
sequence:
STEP DESCRIPTION MESSAGE
DISPLAY FUNCTION AVAILABLE SETTING
1 Primary Input
Range
5
Input Code displayed defines
input type/range (see
App. A) See App. A
Default = 1420
(Type J T/C in °F)
2 Control Action Control Specifies control action
of Output 1
1
dir - Direct Acting
rEv - Reverse Acting (default)
Mdr = Motor drive reverse
Mdd = Motor drive direct
3 Output 2
Usage
10
Out2 Use Specifies use of Output
2
2
out2 - Control Output
A2_d - Alarm 2 (direct)
A2_r - Alarm 2 (reverse)
Or_d - Alarm 1 OR 2 (direct)
Or_r - Alarm 1 OR 2 (reverse)
Ad_d - Alarm 1 AND 2 (direct)
Ad_r - Alarm 1 AND 2 (reverse)
LP_d - Loop Alarm (direct)
LP_r - Loop Alarm (reverse)
4 Output 3
Usage
10
Out3 Use Specifies use of Output
3
3
Al_d - Alarm 1 (direct)
Al_r - Alarm 1 (reverse)
Or_d - Alarm 1 OR 2 (direct)
Or_r - Alarm 1 OR 2 (reverse)
Ad_d - Alarm 1 AND 2 (direct)
Ad_r - Alarm 1 AND 2 (reverse)
LP_d - Loop Alarm (direct)
LP_r - Loop Alarm (reverse)
rEcS - Rcdr Output (SP)
rEcP - Rcdr Output (PV)
5 Segment Mode Seg Mode Defines parameter used
to specify duration of
each segment (along
with final SP value ti - Time
rA - Ramp Rate
Default = ti
6 Baud Rate
6
Baud Rate Selects Baud Rate for
RS485 Comms. Numeric value: 1200, 2400, 4800
or 9600
Default = 4800
7 Protocol
6
Protocol Select protocol and
parity for RS485
comms. Mbn = Modbus, no parity
Mbo = Modbus, odd parity
MbE = Modbus, even parity
WES = ASCII
Default = Mbn
8 Address
6, 7
Address Selects RS485 comm.
address Numeric value = 1 - 255 (Modbus),
1 - 99 (ASCII)
9 CJC
4
Enable/Disable
d
CJC Enables/disables cold
junction comp. EnAb-enabled
diSA - disabled
10 Events
10
Events Set event status in Base
Mode (Binary with LSD = Event 1
0100 = Event #3 on, all other
events off
