Atop Industrial Serial Device Server
SE5408A/SE5416A Series
User Manual V 1.0
19
4.2.1 Overview
1 st layer 2 nd layer 3rd layer 4 th layer 5 th layer Descriptions
1.Overview
1.Model name Display Model name
2.Kernel ver. Display kernel version
3. AP ver. Display AP version
4.Lan 1
1.Lan status Display LAN1 status
2.MAC
Display MAC address of
LAN1
5.Lan 2
1.Lan status Display LAN2 status
2.MAC
Display MAC address of
LAN2
4.2.2 Network Settings
1 st layer 2 nd layer 3rd layer 4 th layer 5 th layer Descriptions
2.Network set
1.Lan 1
1.IP config
1.Static IP Change to Static IP mode
2.DHCP Chang to DHCP mode
2.IP address Display/Change LAN1 IP
3.Net mask Display/Change Net mask
4.Gateway
Display/Change the
Gateway IP
2.Lan 2
1.IP config
1.Static IP Change to Static IP mode
2.DHCP Chang to DHCP mode
2.IP address Display/Change LAN2 IP
3.Net mask Display/Change Net mask
4.Gateway
Display/Change Gateway
IP
3.DNS server1
Display/ Change DNS
Server 1 IP address
4.DNS server2
Display/ Change DNS
Server 2 IP address
