Atop Industrial Serial Device Server
SE5408A/SE5416A Series
User Manual V 1.0
108
9.2 Software
Protocols
DHCP Client, DNS, ERPS, HTTP, ICMP, IPv4, NTP, RFC2217, SMTP, SNMP, STP,
Syslog, TCP, Telnet, UDP
Configuration
Serial Manager, Web UI, Serial console, Telnet
Virtual COM
Windows / Linux redirection software
Link Modes
TCP Server
4 connections, Virtual COM, or Reverse Telnet
TCP Client
Dual destinations or Virtual COM
UDP
Up to 8 ranges of IPs
9.3 Pin Assignments
9.3.1 Serial and RJ-45 Connectors
Ethernet
RS-232
RS-422
RS-485
Pin 1
Tx+
RTS
-
-
Pin 2
Tx-
DTR
TX-
-
Pin 3
Rx+
TXD
TX+
-
Pin 4
SG
SG
SG
Pin 5
SG
SG
SG
Pin 6
Rx-
RXD
RX+
Data+
Pin 7
DSR
RX-
Data-
Pin 8
CTS
-
-
