SECTION 3 - SCISSORS ARMS
3121825
3369LE/4069LE/M3369/M4069
99
FIGURE 3-3. SCISSORS ARMS INSTALLATION - 4069LE & M4069 (USA BUILT MACHINES AND ALL
BELGIUM BUILT MACHINES) (Prior to SN 0200152398)
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
Ref
SCISSOR ARMS INSTALLATION
0270854
Ref
USA Built Machines (Prior to SN 0200112285)
H
0272933
Ref
USA Built Machines (SN 0200112285 through 0200152398)
D
0270854
Ref
Belgium Built Machines
H
1
0100011
AR
Compound, Locking
2
0200683
1
Arm Weldment (Bottom Inboard)
3
0200684
1
Arm Weldment (Lower Mid Inboard)
4
0200685
1
Arm Weldment (Center Mid Inboard)
5
0200686
1
Arm Weldment (Upper Mid Inboard)
6
Ref
Arm Weldment (Top Inboard) Options:
6
0200687
1
0270854 Installation
6
0200726
1
0272933 Installation
7
0200688
1
Arm Weldment (Bottom Right Side Outboard)
8
0200689
1
Arm Weldment (Bottom Left Side Outboard)
9
0200690
1
Arm Weldment (Lower Mid Right Side Outboard)
10
0200691
1
Arm Weldment (Lower Mid Left Side Outboard)
11
0200692
1
Arm Weldment (Center Mid Right Side Outboard)
12
0200693
1
Arm Weldment (Center Mid Left Side Outboard)
13
0200694
1
Arm Weldment (Upper Mid Right Side Outboard)
14
0200695
1
Arm Weldment (Upper Mid Left Side Outboard)
15
Ref
Arm Weldment (Top Outboard) Options:
15
0200696
1
0270854 Installation
15
0200727
1
0272933 Installation
16
0362841
2
Bar, Cable Carrier
17
0440234
4
Bushing
18
0440236
52
Bushing
19
0641408
2
Bolt 1/4in-20NC x 1in
20
0641418
2
Bolt 1/4in-20NC x 2 1/4in
21
0641610
2
Bolt 3/8in-16NC x 1 1/4in
22
0681520
2
Bolt 5/16in-18NC x 2 1/2in (Grade 8)
23
0681622
4
Bolt 3/8in-16NC x 2 3/4in (Grade 8)
24
0681624
26
Bolt 3/8in-16NC x 3in (Grade 8)
25
3900325
2
Screw, Machine #10-24NC
26
0721014
2
Screw, Machine #10-24NC
27
0902713
1
Bracket, Limit Switch
28
0940090
32
Bumper, Arm Spacer
29
1670965
1
Cover, Limit Switch
30
1684120
1
Lift Cylinder Assembly - Lower (See CYLINDER SECTION for
Breakdown)
31
1684121
1
Lift Cylinder Assembly - Upper (See CYLINDER SECTION for
Breakdown)
33
3020022
AR
Lube, Lithium Grease
34
3300151
2
Nut, Acorn 1/4in-20NC
35
3311401
32
Nut 1/4in-20NC
36
3311405
4
Locknut 1/4in-20NC
37
3311505
2
Locknut 5/16in-18NC
38
3311605
32
Locknut 3/8in-16NC
39
3311001
4
Locknut #10-32NF
40
3340856
2
Pad, Slide
