SECTION 4 - PLATFORM
3121825 3369LE/4069LE/M3369/M4069 123
FIGURE 4-4. DRIVE/STEER CONTROLLER ASSEMBLY (Prior to SN 0200142020, SN 1200000100
through 0200230091)
ITEM PART NUMBER QTY DESCRIPTION REV
1600308 Ref CONTROLLER ASSEMBLY (Note: Original Equipment
Assembly p/n 1600308 may have been replaced with p/n
1600403 as Service Replacement Assembly. Identify P/N before
ordering replacement components. If equipped with p/n
1600403 refer to next figure.) D
7020527 1 Mechanical Assembly
1 7020503 1 Handle/Housing Assembly
1A 7020520 1 Housing
1B 7020504 1 Plate, Mounting
1C 7020502 1 Gasket
2 7020529 1 Grip Assembly
2A 7020501 1 Switch, Push Button
2A 7020530 1 Switch, Push Button w/wires
2B 7020500 1 Switch, Micro
2C 7020541 1 Grip - Right Half (was p/n 7020531)
2D 7020541 1 Grip - Left Half (was p/n 7020532)
Ref Note: Handle Kit p/n 7020541 includes both right side and
left side grips.
2E 7027365 1 Actuator, Switch (was p/n 7003791)
2F 7011997 1 Trigger
2G 7003790 1 Cap, Rubber
3 7020533 1 Electrical Assembly
3 7020535 2 Resistor
3A 7020509 1 Plate, Mounting - Potentiometer
3B 7020534 1 Potentiometer
3C 7011940 1 Gear, Pinion
3D 7020511 1 Setscrew #6-32 x 1/8in
3 4460265 1 Plug, Male - 9 Pin (Not Shown)
3 4460268 8 Socket, Female (Not Shown)
3 4460266 1 Connector, Receptacle - 9 Pin (Not Shown - Part of Console
Harness)
3 4460267 8 Pin, Male (Not Shown - Part of Console Harness)
4 7020528 2 Screw #10-32NF x 3/8in
