SECTION 4 - PLATFORM
120
3369LE/4069LE/M3369/M4069
3121825
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
14
3340895
1
Pad, Spacer (USA Built Machines) (Prior to SN 0200121050)
14
3340895
1
Pad, Spacer (All Belgium Built Machines)
15
Ref
Control Options:
15
3520080
1
Plug, Hole (2WD)
15
4360387
1
Switch, Push Button (4WD)
16
3900178
4
Screw, Plastite #10-32 x 1/2in
17
3900265
10
Screw, Self-Tapping #8-18 x 3/4in
18
4060802
AR
Guard, Switch
19
4360387
3
Switch, Push Button
20
4360475
1
Switch, Emergency Stop
20
7020175
1
Cap
20A
7020176
1
Block, Contact
21
4360482
1
Switch, Toggle
22
Ref
Control Options:
22
3520079
1
Plug, Hole (3369LE & 4069LE)
22
4360482
1
Switch, Toggle (M3369 & M4069)
23
4420008
38
in/96cm
Tape, Insulation
24
4460470
1
Nut, Terminal
25
4460471
1
Lockwasher, Terminal
26
4460480
1
Connector, Terminal
27
4740120
12
Washer, Nylon
28
4760600
4
Lockwasher #6
29
4791400
4
Starwasher 1/4in
30
4845938
1
Bracket, Box Hanger
31
4846249
1
Lid
32
Ref
Harness, Platform Console Box (Not Shown - See ELECTRICAL
SECTION for Breakdown)
32
4922526
1
Harness - Without Leveling Jacks
32
4922527
1
Harness - With Leveling Jacks
33
Ref
Control Options:
33
3520080
4
Plug, Hole (Without Leveling Jacks)
33
4360387
4
Switch, Push Button (With Leveling Jacks)
34
Ref
Component Options:
34
3520193
1
Plug
34
2920026
1
Lamp, Indicator
34
2920029
1
Bulb, Light
