Page 103
SECTION 3 - SCISSORS ARMS
3121825
3369LE/4069LE/M3369/M4069
103
FIGURE 3-4. SCISSORS ARMS INSTALLATION - 4069LE AND M4069 (USA BUILT MACHINES) (SN
0200152398 through 0200230091)
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
Ref
SCISSOR ARMS ASSEMBLY
0275482
Ref
Without Platform Overload
A
0275526
Ref
With Platform Overload
A
1
0200683
1
Arm Weldment (Bottom Inboard)
2
0200684
1
Arm Weldment (Lower Mid Inboard)
3
0200685
1
Arm Weldment (Center Mid Inboard)
4
0200686
1
Arm Weldment (Upper Mid Inboard)
5
0200726
1
Arm Weldment (Top Inboard)
6
0200688
1
Arm Weldment (Bottom Right Side Outboard)
7
0200689
1
Arm Weldment (Bottom Left Side Outboard)
8
0200690
1
Arm Weldment (Lower Mid Right Side Outboard)
9
0200691
1
Arm Weldment (Lower Mid Left Side Outboard)
10
0200692
1
Arm Weldment (Center Mid Right Side Outboard)
11
0200693
1
Arm Weldment (Center Mid Left Side Outboard)
12
0200694
1
Arm Weldment (Upper Mid Right Side Outboard)
13
0200695
1
Arm Weldment (Upper Mid Left Side Outboard)
14
0200727
1
Arm Weldment (Top Outboard)
15
0440250
4
Bushing
16
0440236
52
Bushing
17
0940090
32
Bumper, Arm Spacer
18
3311401
32
Nut 1/4in-20NC
19
4711500
32
Flatwasher 5/16in Narrow
22
0100011
AR
Compound, Locking
23
0362841
2
Bar, Cable Carrier
24
0641418
2
Bolt 1/4in-20NC x 2 1/4in
26
0681622
4
Bolt 3/8in-16NC x 2 3/4in (Grade 8)
27
0681624
26
Bolt 3/8in-16NC x 3in (Grade 8)
31
1320110
1
Clamp, Support
32
1320122
1
Clamp
33
1670995
1
Cover, Hose/Cable
34
1684120
1
Lift Cylinder Assembly - Lower (See CYLINDER SECTION for
Breakdown)
35
1684121
1
Lift Cylinder Assembly - Upper (See CYLINDER SECTION for
Breakdown)
44
3300151
2
Nut, Acorn 1/4in-20NC
45
3311605
30
Locknut 3/8in-16NC
47
3422369
1
Pin, Plunger
48
3422778
4
Pin, Pivot
49
3422825
24
Pin, Pivot
50
3422826
2
Pin, Pivot
51
3450304
4
Pin, Cotter 3/32in x 1in
53
3760420
26
Ring, Retaining
54
4280295
6 in/15cm
Strip, Protective
59
4711600
1
Flatwasher 3/8in Thin
60
4740332
26
Washer, Special
61
4740480
4
Washer, Plastic Insert
62
4751500
4
Flatwasher 5/16in
63
4846020
1
Prop, Safety
64
4922478
1
Platform Harness (Not Shown - See ELECTRICAL SECTION for
