SECTION 1 - FRAME
3121825 3369LE/4069LE/M3369/M4069 55
FIGURE 1-13. BATTERY CHARGER ASSEMBLY (MAC CHARGER)
ITEM PART NUMBER QTY DESCRIPTION REV
Ref MAC BATTERY CHARGER ASSEMBLIES
0400190 Ref 120V-240VAC/50-60HZ (CE Spec) B
0400191 Ref 250VAC/50HZ (Australian Spec) C
1 7020653 AR Breaker, Circuit - 20 Amp
2 7011621 1 Connector - 2 Position
3 Ref PC Board Options:
3 7022924 1 120V-240VAC/50-60HZ (CE Spec)
3 7022906 1 250VAC/50HZ (Australian Spec) (Was p/n 7020643)
4 7020644 1 Cord, DC
5 7018571 1 Holder, Fuse (Not Shown)
6 7018570 1 Fuse - 80 DC Amp
7 7020645 1 Harness - 17 Position
8 7020646 1 Harness - 4 Position
9 7018571 1 Holder, Fuse
10 7020648 1 Plug, AC Inlet
11 7011590 1 Plug, DC
12 7020649 2 Rectifier, Replacement
13 7020650 2 SCR, Replacement
14 Ref Relay Options:
14 7020654 1 120V-240VAC/50-60HZ (CE Spec)
14 7018535 1 250VAC/50HZ (Australian Spec)
15 7020651 1 Shunt Assembly
16 7011529 2 Connector, Strain Relief (Not Shown)
17 Ref Transformer Options:
17 7020662 1 120V-240VAC/50-60HZ (CE Spec)
17 7020683 1 250VAC/50HZ (Australian Spec)
18 7018537 1 Varistor
19 Ref Controller Options:
19 7020640 AR 120V-240VAC/50-60HZ (CE Spec)
19 Not Required 0 250VAC/50HZ (Australian Spec)
20 Ref Relay Options:
20 7018564 AR 120V-240VAC/50-60HZ (CE Spec)
20 Not Required 0 250VAC/50HZ (Australian Spec)
