SECTION 3 - SCISSORS ARMS
3121825
3369LE/4069LE/M3369/M4069
95
FIGURE 3-2. SCISSORS ARMS INSTALLATION - 3369LE AND M3369 (USA BUILT MACHINES) (SN
0200152398 through 0200230091)
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
Ref
SCISSOR ARMS ASSEMBLY
0275481
Ref
Without Platform Overload
A
0275525
Ref
With Platform Overload
A
1
0200654
1
Arm Weldment (Bottom Inboard)
2
0200655
1
Arm Weldment (Lower Mid Inboard)
3
0200656
1
Arm Weldment (Upper Mid Inboard)
4
0200724
1
Arm Weldment (Top Inboard)
5
0200658
1
Arm Weldment (Bottom Left Side Outboard)
6
0200659
1
Arm Weldment (Lower Mid Left Side Outboard)
7
0200660
1
Arm Weldment (Upper Mid Left Side Outboard)
8
0200725
1
Arm Weldment (Top Outboard)
9
0200667
1
Arm Weldment (Bottom Right Side Outboard)
10
0200668
1
Arm Weldment (Lower Mid Right Side Outboard)
11
0200669
1
Arm Weldment (Upper Mid Right Side Outboard)
12
0440250
4
Bushing
13
0440236
40
Bushing
14
0641510
24
Bolt 5/16in-18NC x 1 1/4in
15
3311505
24
Locknut 5/16in-18NC
16
3340866
24
Pad, Arm
17
4711500
24
Flatwasher 5/16in Thin
20
0100011
AR
Compound, Locking
21
0362840
1
Bar, Cable Carrier
22
0362841
1
Bar, Cable Carrier
23
0641418
2
Bolt 1/4in-20NC x 2 1/4in
25
0681622
2
Bolt 3/8in-16NC x 2 3/4in (Grade 8)
26
0681624
20
Bolt 3/8in-16NC x 3in (Grade 8)
29
1060866
1
Cable, Electrical - 12/3 (Not Shown - See ELECTRICAL
SECTION for Breakdown)
30
1320110
1
Clamp, Support
31
1320122
1
Clamp
32
1670995
1
Cover, Hose/Cable
33
1684119
1
Lift Cylinder Assembly (See CYLINDER SECTION for
Breakdown)
38
3300151
2
Nut, Acorn 1/4in-20NC
39
3311605
22
Locknut 3/8in-16NC
41
3422369
1
Pin, Plunger
42
3422778
2
Pin, Pivot
43
3422825
16
Pin, Pivot
44
3422826
4
Pin, Pivot
45
3450304
4
Pin, Cotter 3/32in x 1in
47
3760420
20
Ring, Retaining
48
4280295
6 in/15cm
Strip, Protective
52
4711600
1
Flatwasher 3/8in Thin
53
4740332
20
Washer, Special
54
4740480
4
Washer, Plastic Insert
55
4751500
4
Flatwasher 5/16in
56
4846020
1
Prop, Safety
57
4922477
1
Platform Harness (Not Shown - See ELECTRICAL SECTION for
Breakdown)
