SECTION 5 - CYLINDER
144 3369LE/4069LE/M3369/M4069 3121825
ITEM PART NUMBER QTY DESCRIPTION REV
119 7024101 1 1684120 Cylinder
119 7019862 1 1684121 Cylinder
120 Ref Spacer Options:
120 7023509 1 1684120 Cylinder
120 7023510 1 1684121 Cylinder
Ref OVERLOAD CUT-OUT INSTALLATIONS (FRENCH SPEC)
Ref USA Manufactured (Prior to SN 0200098313)
Ref Belgium Manufactured (Prior to SN 1200000398)
0271404 Ref Lift Down Cut-Out C
0271482 Ref All Function Cut-Out B
201 0100020 AR Sealant, Pipe
202 2220440 1 Fitting, Straight
203 2220654 1 Fitting, 90
204 2221020 1 Fitting, Straight
205 4360507 1 Switch, Pressure
206 4460428 1 Connector, Strain Relief
207 4922596 1 Harness, Overload (See ELECTRICAL SECTION for
Breakdown)
Ref OVERLOAD CUT-OUT INSTALLATIONS (FRENCH SPEC)
Ref NOTE: Used on USA Manufactured Machines with SN
0200098313 to SN 0200112285 and Belgium Manufactured
Machines with SN 1200000398 to SN 1200000844 Only. For
Machines with Overload Refer to JLG Supplement p/n
3124288.
0271652 Ref Overload Cut-Out Installations (French Spec) 4069LE/M4069 C
301 4360518 1 Transducer, Pressure
307 2221116 1 Fitting 90
310 4922686 1 Harness, Overload (See ELECTRICAL SECTION for
Breakdown)
Ref KIT OPTIONS:
Ref Seal Kit Options (Includes Items 101 to 109):
400 7024103 1 1684120 Cylinder
401 7024102 1 1684121 Cylinder
