JLG M4069 Parts Manual - Manual (Page 177)

SECTION 7 - ELECTRICAL
3121825 3369LE/4069LE/M3369/M4069 177
ITEM PART NUMBER QTY DESCRIPTION REV
418D 4460884 1 Plug, Male - 4 Position
418D 4460465 AR Socket, Female
418E Ref Connector Options:
418E 4460894 1 Plug, Male - 6 Position
418E 4460931 1 Receptacle, Female - 8 Position
418E 4460464 AR Pin, Male
418E 4460465 AR Socket, Female
418E 4460466 AR Plug, Sealing
419 Not Available 1 Harness, Speed Sensor (4WD Only)
419A 7024928 1 Receptacle, Female - 4 Position
419A 4460464 AR Pin, Male
420 70000328 1 Harness, Generator Control (M3369 & M4069)
420A 4460224 1 Connector, Female - 6 Position
420A 4460226 5 Socket, Female
420B 4460761 1 Connector, Female - 4 Position
420B 4460227 4 Pin, Male
421 Ref Harness, Generator Options:
421 4922529 1 Harness, Generator M3369 & M4069 with Leveling Jacks (See
OPTIONAL ELECTRICAL COMPONENTS INSTALLATION for
Breakdown)
421 4922602 1 Harness, Generator M3369 & M4069 without Leveling Jacks A
421A 4460225 1 Plug, Male - 6 Position
421A 4460227 4 Pin, Male
421B 4460896 1 Plug, Male - 24 Position
421C 4460465 4 Socket, Female
424 Ref Harness, Motor/Generator Options:
424 7023486 1 Yanmar Engine
424 70000328 1 Kubota Engine
424 70000329 1 Fuse 15 Amp (Kubota Engine)
424 70000330 1 Fuse 20 Amp (Kubota Engine)
425 Not Available 1 Harness, Controller (Part of Electrical Assembly)
425A 4460265 1 Plug, Male - 9 Position
425A 4460268 8 Socket, Female
426 Ref Plug Charger Installation
426 4460805 Ref Australian Spec (250VAC/50HZ)
426 Ref CE Specs:
426 0275663 Ref 220V with CEE 7 Post Ground Receptacle, Plug and Circuit
Breaker (70mm x 70mm Box) A
426 0275664 Ref 220V with CEE 7 Side Ground Receptacle, Plug and Circuit
Breaker (70mm x 70mm Box) A
426 0275665 Ref 220V with AFSINT 107 Keyed Ground Receptacle, Plug and
Circuit Breaker (2x4 Box) A
426 0275666 Ref 110V with IEC Yellow Receptacle, Plug and Circuit Breaker A
426 0275667 Ref 220V with IEC Blue Receptacle, Plug and Circuit Breaker A
426 Ref Plug Options:
426 4461202 1 0275663 Installation
426 4461205 1 0275664 Installation
426 4461249 1 0275665 Installation
426 4461196 1 0275666 Installation
426 4461199 1 0275667 Installation
427 4460802 1 Cover, Plug
428 4460428 1 Connector, Strain Relief
