SECTION 1 - FRAME
3121825 3369LE/4069LE/M3369/M4069 33
FIGURE 1-8. DRIVE MOTOR ASSEMBLY (REAR)
ITEM PART NUMBER QTY DESCRIPTION REV
3160256 Ref DRIVE MOTOR ASSEMBLY C
1 7020184 1 Plate, Drive End
2 7012545 1 Bearing
3 7020185 1 Ring, Retaining
4 7023343 1 Armature
5 See Note NSS Frame and Field Assembly (Note: Purchase Complete Assembly)
6 7012548 4 Spring, Brush
7 7012547 4 Brush
8 7023344 1 Holder, Brush
9 7023229 2 Brush Lead Assembly Kit
10 7012545 1 Bearing
11 7012549 1 Washer, Wavy
12 7020189 1 End, Commutator
13 7019609 1 Headband Assembly
