SECTION 5 - CYLINDER
3121825 3369LE/4069LE/M3369/M4069 147
FIGURE 5-8. STEER CYLINDER ASSEMBLY
ITEM PART NUMBER QTY DESCRIPTION REV
1683994 Ref STEER CYLINDER ASSEMBLY C
1 7001626 1 Locknut
2 See Note 1 Seal, Piston (Note: use p/n 70002517)
3 See Note 1 O-Ring (Note: use p/n 70002517)
4 70002518 1 Piston (was p/n 7017291)
5 7023022 1 Barrel
6 7023021 1 Rod
7 7017294 1 Guide
8 See Note 1 O-Ring (Note: use p/n 70002517)
9 See Note 1 Ring, Back-up (Note: use p/n 70002517)
10 See Note 1 Seal (Note: use p/n 70002517)
11 See Note 1 Wiper (Note: use p/n 70002517)
12 See Note 1 Ring, Retainer (Note: use p/n 70002517)
13 See Note 1 O-Ring (Note: use p/n 70002517)
Ref KIT OPTIONS:
100 70002517 1 Seal Kit Options (Includes Items 2, 3 & 8-13) (was p/n 7017290)
