SECTION 5 - CYLINDER
3121825 3369LE/4069LE/M3369/M4069 137
FIGURE 5-5. LEVELING JACK CYLINDER ASSEMBLY (USA BUILT MACHINES) (SERVICE
REPLACEMENT) (SN 0200214444 through 0200230091)
ITEM PART NUMBER QTY DESCRIPTION REV
1001140600 Ref LEVELING JACK CYLINDER ASSEMBLY A
1 70003826 1 Barrel
2 70003827 1 Rod
4 70003818 1 Head
5 70003819 1 Piston
6 See Note 1 Seal, Piston (Note: use p/n 70003829)
7 70002216 1 Retainer
8 See Note 1 Seal, Rod (Note: use p/n 70003829)
10 See Note 1 Seal, Wiper (Note: use p/n 70003829)
11 See Note 1 O-Ring (Note: use p/n 70003829)
12 See Note 1 Ring, Back-up (Note: use p/n 70003829)
13 70003820 1 O-Ring
16 See Note 1 O-Ring (Note: use p/n 70003829)
17 See Note 1 O-Ring (Note: use p/n 70003829)
19 7017406 2 Plug
20 7024844 2 Plug
21 4641156 1 Valve, Check
21 2900770 1 Seal Kit - 4641156 Valve
22 4640495 1 Valve, Counter Balance
22 2900770 1 Seal Kit - 4640495 Valve
24 70003828 1 Pad, Jack
25 70003821 1 Plate
26 70003822 2 Ring, Retaining
27 70003823 3 Screw, Special 1/2in-13NC x 1-1/4in
28 70003824 1 Spacer
30 70002219 1 Ring, Retaining
31 70003825 3 Lockwasher
32 See Note 2 Ring, Wear (Note: use p/n 70003829)
50 70003829 1 Seal Kit (Includes Items 6, 8-12, 16, 17 & 32)
