SECTION 1 - FRAME
46
3369LE/4069LE/M3369/M4069
3121825
FIGURE 1-11. KUBOTA MOTOR/GENERATOR AND BATTERY CHARGER INSTALLATION (M3369
AND M4069 ONLY)
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
Ref
Note: Only used on USA Built Machines.
0274684
Ref
ENGINE INSTALLATION - KUBOTA DIESEL (Prior to SN
0200225601)
G
1001159360
Ref
ENGINE INSTALLATION - KUBOTA DIESEL (SN 0200225601
through 0200230091)
A
1
0100011
AR
Compound, Locking
2
0100020
AR
Sealant
4
0400201
1
Battery
5
0610131
1
LED PC Board Assembly
6
0641418
4
Bolt 1/4in-20NC x 2-1/4in
9
0641604
2
Bolt 3/8in-16NC x 1/2in
10
0641632
2
Bolt 3/8in-16NC x 4in
11
0641660
2
Bolt 3/8in-16NC x 7-1/2in
12
0902659
1
Bracket, Battery
13
1060820
1
Cable, Battery (+)
14
1060916
1
Cable, Battery (-)
15
1060917
1
Cable, Battery (+)
16
1060950
1
Cable, Battery (-)
19
1671010
1
Cover, Engine
21
1704830
1
Decal - Battery Charger (Prior to SN 0200199013)
23
2220805
1
Fitting, 90 Coupling
26
2680491
1
Kit, Front Cover (use p/n 2902141) (Includes Items 5)
29
2820135
1
Insulation (Engine Cover)
30
2820136
1
Insulation (Frame Left Side)
31
2820137
1
Insulation (Engine Cover)
32
2820138
1
Insulation (Frame Right Side)
33
2820228
1
Insulation (Front Cover)
35
2940137
1
Latch
36
3300374
1
Nut, Binding
37
3311405
4
Locknut 1/4in-20NC
39
3311605
4
Locknut 3/8in-16NC
40
3322202
4
Nut, Jam 3/4in
41
3760348
4
Ring, Retaining
42
3841233
4
Rod, Roller
43
3860059
4
Roller, Extension
44
3900184
1
Screw, Button Head #10-24NC x 5/8in
45
3960389
2 ft/61cm
Seal
46
3960418
2 ft/61cm
Seal
47
4160189
1
Spring, Extension
49
4711400
8
Flatwasher 1/4in Thin
52
4751600
6
Flatwasher 3/8in Regular
53
4752200
6
Flatwasher 3/4in Regular
2000327
Ref
GENERATOR ASSEMBLY (Prior to SN 0200225601)
F
1001159358
Ref
GENERATOR ASSEMBLY (SN 0200225601 through 0200230091)
A
101
0641410
2
Bolt 1/4in-20NC x 1-1/4in
102
0641609
8
Bolt 3/8in-16NC x 1-1/8in
103
0641616
4
Bolt 3/8in-16NC x 2in
104
0641820
4
Bolt 1/2in-13NC x 2-1/2in
105
1320135
1
Clamp, Muffler
