SECTION 1 - FRAME
36 3369LE/4069LE/M3369/M4069 3121825
ITEM PART NUMBER QTY DESCRIPTION REV
105 See Note 1 Seal, Shaft (Note: Use Item 300)
106 Ref Bearing, Rear Options:
106 7022588 1 3160245 & 1001101934 Motors
106 See Note NSS 3160267 Motor (Note: Purchase Complete Motor Assembly)
107 See Note NSS Washer (Note: Not Available for Purchase)
108 7022589 1 Ring, Split
Ref REAR HOUSING ASSEMBLY
201 Ref Ring, Distributor Options:
201 See Note NSS 3160245 & 3160267 Motors (Note: Purchase Complete Motor
Assembly)
201 70002267 1 1001101934 Motor
202 Ref Spring Options:
202 See Note NSS 3160245 & 3160267 Motors (Note: Purchase Complete Motor
Assembly)
202 7023872 9 1001101934 Motor
203 See Note 1 Seal, Nylon (Note: Use Item 300)
204 See Note AR Seal, Nylon (Note: Use Item 300)
205 See Note 1 Seal, Nylon (Note: Use Item 300)
206 Ref Housing, Rear
206 See Note NSS 3160245 & 3160267 Motors (Note: Purchase Complete Motor
Assembly)
206 See Note 1 1001101934 Motor (Note: use p/n 70002263)
207 Ref Pin, Stop Options:
207 7022590 1 3160245 & 3160267 Motors
207 70002268 1 1001101934 Motor
208 Ref Plug (O-Ring Supplied with Plug)
208 7022591 1 3160245 & 3160267 Motors
208 2220890 1 1001101934 Motor
Ref KIT OPTIONS
300 Ref Seal Kit Options (Includes Items 4, 102, 105 & 203-205):
300 7023801 1 3160245 & 3160267 Motors
300 70002269 1 1001101934 Motor
