JLG M4069 Parts Manual User Manual
Page 61
SECTION 1 - FRAME
3121825
3369LE/4069LE/M3369/M4069
61
FIGURE 1-16. ELECTRICAL COMPONENTS INSTALLATIONS (FRAME MOUNTED)
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
Ref
ELECTRICAL DRIVE COMPONENTS INSTALLATIONS
0270473
Ref
USA Built Machines (Prior to SN 0200174517)
H
1001099375
Ref
USA Built Machines (SN 0200174517 through 0200230091)
A
0270473
Ref
Belgium Built Machines
H
2
0100083
AR
Grease, Heat Transfer
4
0641406
2
Bolt 1/4in-20NC x 3/4in
5
0641412
4
Bolt 1/4in-20NC x 1 1/2in
12
1060888
1
Cable, Electrical (Controller F2 to Right Motor S1)
13
1060889
1
Cable, Electrical (Right Motor S2 to Left Motor S2)
14
1060890
1
Cable, Electrical (Controller F1 to Left Motor S2)
15
1060891
1
Cable, Electrical (Controller S to Right Motor A1)
16
1060892
1
Cable, Electrical (Left Motor A1 to Right Motor A1)
17
1060893
1
Cable, Electrical (Controller A to Right Motor A2)
18
1060894
1
Cable, Electrical (Left Motor A2 to Right Motor A2)
19
1060895
1
Cable, Electrical (Contactor to Controller B+)
20
Ref
Controller, Sevcon Options:
20
1600311
NLA
USA Built Machines (use p/n 1600421) (Prior to SN
0200130959)
20
1600421
1
USA Built Machines (SN 0200130959 through 0200230091)
20
1600311
NLA
Belgium Built Machines (use p/n 1600421)
24
3311405
6
Locknut 1/4in-20NC
26
3740135
1
Contactor
27
4240084
1
Strap, Anti-Static
28
4711400
4
Flatwasher 1/4in Thin
31
4751400
8
Flatwasher 1/4in Regular
34
3941606
1
Screw, Self-Tapping 3/8in-16NC x 3/4in
35
4751600
1
Flatwasher 3/8in Regular
