SECTION 2 - GROUND CONTROLS
3121825 3369LE/4069LE/M3369/M4069 85
FIGURE 2-5. PUMP ASSEMBLY
ITEM PART NUMBER QTY DESCRIPTION REV
Ref GEAR PUMP ASSEMBLY
3600319 Ref USA Built Machines (Prior to SN 0200115069) B
3600367 Ref USA Built Machines (SN 0200115069 through 0200230091) A
3600319 Ref All Belgium Built Machines B
1 See Note NSS Body (Note: Purchase Complete Assembly)
2 See Note NSS Cover, Front (Note: Purchase Complete Assembly)
3 See Note NSS Cover, Rear (Note: Purchase Complete Assembly)
4 See Note NSS Gear, Drive (Note: Purchase Complete Assembly)
5 See Note NSS Gear, Idler (Note: Purchase Complete Assembly)
6 See Note 2 Block, Bearing (Note: Use Item 14)
7 See Note 2 Seal, Load (Note: Use Item 14)
8 See Note 2 Seal, Anti-Extrusion (Note: Use Item 14)
9 See Note 1 Seal, Shaft (Note: Use Item 14)
10 See Note 2 Pin, Dowel (Note: Purchase Locally)
11 See Note 2 Ring, Square (Note: Use Item 14)
12 See Note 4 Washer (Note: Purchase Locally)
13 See Note 4 Capscrew (Note: Purchase Locally)
14 Ref Seal Kit Options:
14 Ref Minor Seal Kit Options (Includes Items 7, 8, 9 & 11):
14 7023808 1 3600319 Pump
14 7024960 1 3600367 Pump
14 Ref Major Seal Kit Options (Includes Items 6, 7, 8, 9 & 11):
14 7023819 1 3600319 Pump
14 7024961 NLA 3600367 Pump (Note: Use Minor Seal Kit or Replace
Complete Assembly)
