SECTION 1 - FRAME
40
3369LE/4069LE/M3369/M4069
3121825
FIGURE 1-10. YANMAR MOTOR/GENERATOR AND BATTERY CHARGER INSTALLATION (M3369
AND M4069 ONLY)
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
0270788
Ref
ENGINE INSTALLATION - YANMAR DIESEL
K
1
0100011
AR
Compound, Locking
4
0270787
1
Generator Assembly (See 101 to 187 for Breakdown)
5
0400201
1
Battery
6
3960418
2 ft/61cm
Seal
7
0641418
4
Bolt 1/4in-20NC x 2-1/4in
10
0641632
2
Bolt 3/8in-16NC x 4in
11
0641660
2
Bolt 3/8in-16NC x 7-1/2in
12
0902659
1
Bracket, Battery
13
Ref
Cable, Battery (-) Options:
13
1060819
1
USA Manufactured (Prior to SN 0200102732)
13
1060950
1
USA Manufactured (SN 0200102732 through 0200230091)
13
1060950
1
Belgium Manufactured (SN 1200000398 to Present)
14
1060820
1
Cable, Battery (+)
17
1671010
1
Cover, Engine
20
2902141
1
Cover, Front (was p/n 2680491)
22
2820134
1
Insulation (Front Cover)
23
2820135
1
Insulation (Engine Cover)
24
2820136
1
Insulation (Frame Left Side)
25
2820137
1
Insulation (Engine Cover)
26
2820138
1
Insulation (Frame Right Side)
27
2940137
1
Latch
28
3300374
1
Nut, Binding
29
3311405
8
Locknut 1/4in-20NC
31
3311605
4
Locknut 3/8in-16NC
32
3322202
4
Nut, Jam 3/4in
33
3760348
4
Ring, Retaining
34
3841233
4
Rod, Roller
35
3860059
4
Roller, Extension
36
3900184
1
Screw, Button Head #10-24NC x 5/8in
37
4160189
1
Spring, Extension
39
4711400
16
Flatwasher 1/4in Narrow
42
4751600
6
Flatwasher 3/8in
43
4752200
4
Flatwasher 3/4in
45
1060916
1
Cable, Battery (-)
46
1060917
1
Cable, Battery (+)
47
3960389
2 ft/61cm
Seal
49
0641604
2
Bolt 3/8in-16NC x 1/2in
50
1701505
2
Decal - Diesel Fuel (Not Shown - Located on Hood)
51
4922602
1
Harness, Generator (Not Shown - See ELECTRICAL SECTION for
Breakdown) (USA Manufactured Only) (Prior to SN 0200100178)
52
Ref
Fitting, Straight Barb
52
2220315
1
USA Manufactured Only (SN 0200097450 through 0200230091)
52
2220315
1
Belgium Manufactured Only (SN 1200000398 to Present)
54
Ref
LED PC Board Assembly
54
0610131
1
USA Manufactured Only (SN 0200104581 through 0200230091)
54
0610131
1
Belgium Manufactured Only (SN 1200000398 to Present)
2902141
1
Kit, Generator Hood/PC (Includes Items 20 & 54)
2902423
1
Kit, Service Addition of A Separate Fuse Engine Control Mechron
