Page 115
SECTION 4 - PLATFORM
3121825
3369LE/4069LE/M3369/M4069
115
FIGURE 4-2. FOLDDOWN HANDRAILS AND EXTENSION INSTALLATION (MANUALLY OPERATED
PLATFORM)
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
Ref
FOLDDOWN HANDRAILS INSTALLATIONS OPTIONS:
0259568
Ref
Self-Closing Welded Gate
I
1
4846123
2
Side Rail Weldment
2
4846124
1
Rear Rail Weldment (Left Side)
3
4846125
1
Rear Rail Weldment (Right Side)
4
4846122
1
Gate Weldment
5
2600253
2
Hinge
6
2080069
12
Fastener #10-32NF
7
3900267
12
Screw, Socket Head
8
2940074
1
Latch
9
3571829
1
Plate, Latch
11
0901870
2
Bracket
12
3421565
3
Pin, Snap
13
3760170
5
Ring, Split
15
0641516
3
Bolt 5/16in-18NC x 2in
16
Ref
Nut Options:
16
3300356
10
Nut, Acorn 5/16in-18NC
16
2080064
10
Nut, Nylon Lock 5/16in-18NC
17
3300432
4
Nut, Acorn #10-24NC
18
3311505
3
Locknut 5/16in-18NC
19
3911010
4
Screw #10-24NC x 3/4in
21
3900323
9
Screw 5/16in-18NC x 2in (was p/n 3911532)
22
4751000
16
Flatwasher #10 Regular
23
4751500
6
Flatwasher 5/16in Regular
24
2540020
1
Grommet
25
3422219
2
Pin, Snap
26
0100011
AR
Compound, Locking
27
Ref
Nut Options:
27
3300151
AR
Nut, Acorn 1/4in-20NC
27
2080063
AR
Nut, Nylon Lock 1/4in-20NC
28
1060808
5
Lanyard
29
3911536
1
Screw 5/16in-18NC x 2-1/4in
30
Ref
Screw Options:
30
3911428
2
Screw, Hex 1/4in-20NC x 1-3/4in
30
3900318
2
Screw, Torx Drive 1/4in-20NC x 1-3/4in
31
Ref
Clamp
31
1320061
1
USA Built Machines (SN 0200099149 through 0200230091)
31
1320061
1
Belgium Built Machines (SN 1200000398 to Present)
32
4711400
2
Flatwasher 1/4in Thin
0259565
Ref
PLATFORM EXTENSION INSTALLATION
L
101
4846117
1
Extension Weldment
102
3537619
4
Mounting Weldment - Roller
103
3841233
4
Rod, Roller
104
3760348
4
Ring, Retaining
105
3860059
4
Roller, Extension
106
3322202
4
Nut, Jam 3/4in
107
4846121
1
Side Rail Weldment (Left Side)
108
4846120
1
Front Rail Weldment
109
3537609
2
Plate, Pivot
