SECTION 1 - FRAME
22 3369LE/4069LE/M3369/M4069 3121825
ITEM PART NUMBER QTY DESCRIPTION REV
Ref TIRE AND WHEEL INSTALLATIONS
0270570 Ref IN240/55 x17.5 (Foam-Filled Tire with JLG in Tread Pattern) B
0270581 Ref IN240/55 x 17.5 (Non-Marking Foam-Filled Tire with JLG in
Tread Pattern) (Prior to SN 0200114833) A
0273477 Ref IN240/55 x 17.5 (Non-Marking Foam-Filled Tire with Lightning
in Tread Pattern) (SN 0200114833 through 0200230091) A
0270523 NLA 240/55 x D17.5 R4 Tread (Non-Marking Foam-Filled All Lug
Tire) (4069LE/M3369/M4069 Only) (No Longer Used - Use p/n
0273477 as Replacement) D
0271690 NLA 240/55 x D17.5 R4 Tread (Non-Marking Foam-Filled All Lug
Tire) (3369LE Only) (No Longer Used - Use p/n 0273477 as
Replacement) C
0270627 Ref 27.2/10.5LL - 15.0 (Turf Tire) B
201 Ref Tire and Wheel Assembly Options:
201 0258997 4 IN240/55 x17.5 (Foam-Filled - See Note) (JLG in Tread Pattern) 1-B
201 0270417 4 IN240/55 x 17.5 (Non-Marking Foam-Filled - See Note) (JLG in
Tread Pattern) (Prior to SN 0200114833) 2-B
201 0273468 4 IN240/55 x 17.5 (Non-Marking Foam-Filled - See Note)
(Lightning Tread Pattern) (SN 0200114833 through
0200230091) D
201 0271948 NLA 240/55 x D17.5 R4 Tread (Left Side) (Non-Marking Foam-Filled
All Lug Tire) (Use p/n 0273468) (See Assembly Note Also)
201 0271949 NLA 240/55 x D17.5 R4 Tread (Right Side) (Non-Marking Foam-
Filled Tire All Lug Tire) (Use p/n 0273468) (See Assembly Note
Also)
201 0270530 4 27.2/10.5LL - 15.0 (Turf Tire) D
Ref Note: Assemblies may require ballast/foam filling to
manufacturer's specification prior to installing on a machine.
Refer to Operation and Safety or Service and Maintenance
Manuals. Purchase individual tire and/or rim only if able to
foam fill tire and wheel assembly, otherwise, purchase
complete assembly.
201A Ref Tire Options (See Note):
201A 4520209 4 IN240/55 x17.5 (JLG in Tread Pattern)
201A 4520247 4 IN240/55 x 17.5 (Non-Marking Foam-Filled Tire with JLG in
Tread Pattern) (Prior to SN 0200114833)
201A 4520269 4 IN240/55 x 17.5 (Non-Marking Foam-Filled Tire with
Lightning Tread Pattern (SN 0200114833 through
0200230091)
201A 4520260 NLA 240/55 x D17.5 R4 Tread (Non-Marking Foam-Filled All Lug
Tire) (Use p/n 0273468)
201A 4520249 4 27.2/10.5LL - 15.0 (Turf Tire)
201B Ref Valve, Air Options:
201B 4640392 4 Valve (0258997, 0270417 & 0273477 Installations)
201B 4640113 4 Valve (0270523, 0270627 & 0271690 Installations)
201C Ref Rim, Wheel Options (See Note):
201C 4860222 4 6.75 x 17.5
201C 4860191 4 6.812 x 17.5
201C 4860221 4 8.0 x 15.0
202 3300426 36 Lugnut
