Page 59
SECTION 1 - FRAME
3121825
3369LE/4069LE/M3369/M4069
59
FIGURE 1-15. INVERTER INSTALLATIONS (3369LE AND 4069LE ONLY)
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
0271344
Ref
INVERTER INSTALLATION (OPTIONAL)
C
1
0100011
AR
Compound, Locking
2
0641404
4
Bolt 1/4in-20NC x 1/2in
3
Ref
AC Cable Assembly Options (Not Shown - See ELECTRICAL
SECTION):
3
1060910
1
USA Built Machines (Prior to SN 0200099496)
3
1060933
1
USA Built Machines (SN 0200099496 through 0200230091)
3
1060933
1
Belgium Built Machines
4
Ref
Cable, Positive Options (Not Shown - See ELECTRICAL
SECTION):
4
1060911
1
USA Built Machines (Prior to SN 0200099496)
4
1060934
1
USA Built Machines (SN 0200099496 through 0200230091)
4
1060934
1
Belgium Built Machines
5
Ref
Cable, Negative Options (Not Shown - See ELECTRICAL
SECTION):
5
1060912
1
USA Built Machines (Prior to SN 0200099496)
5
1060935
1
USA Built Machines (SN 0200099496 through 0200230091)
5
1060935
1
Belgium Built Machines
6
2460037
1
Inverter
7
4711400
4
Flatwasher 1/4in Narrow
8
Ref
Plate, Mounting Options:
8A
4846411
1
USA Built Machines (Prior to SN 0200099496)
8B
4846520
1
USA Built Machines (SN 0200099496 through 0200230091)
8B
4846520
1
Belgium Built Machines
9
0630549
4
Bolt 3/8in-16NC x 1 1/4in
10
0641608
1
Bolt 3/8in-16NC x 1in
11
0902780
1
Bracket, Switch Mount
12
1705052
1
Decal - Inverter ON/OFF
13
1705051
1
Decal - Inverter
14
3311604
1
Locknut 3/8in-16NC
15
4360482
1
Switch, Toggle
16
4751600
1
Flatwasher 3/8in (Wide)
17
4922668
1
Cable
