SECTION 1 - FRAME
42
3369LE/4069LE/M3369/M4069
3121825
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
184
7020217
1
Element, Air Filter
185
7020200
1
Regulator, Voltage (Not Shown)
186
7026669
1
Spring, Governor
187
7026670
1
Spring, Return
Ref
BATTERY CHARGER INSTALLATION
0270841
Ref
120V-240VAC/50-60HZ (CE Spec)
C
0270842
Ref
250VAC/50HZ (Australian Spec)
C
201
0100011
AR
Compound, Locking
202
Ref
Battery Charger Options (See BATTERY CHARGER
ASSEMBLY (MAC CHARGER) for Breakdown)
202
0400190
1
120V-240VAC/50-60HZ (CE Spec)
202
0400191
1
250VAC/50HZ (Australian Spec)
203
Ref
LED PC Board Assembly
203
0610131
1
USA Manufactured Only Only (Prior to SN 0200104581)
204
0641407
4
Bolt 1/4in-20NC x 7/8in
205
1060759
1
Cable, Electrical
206
1060913
1
Cable, Harness - LED Light
207
0721008
4
Screw #10-24NC x 1in
208
3311005
4
Locknut #10-24NC
209
4460802
1
Cover, Plug
210
Ref
Plug Options:
210
Ref
CE Spec (See ELECTRICAL SECTION for Breakdown)
210
4460805
1
250VAC/50HZ (Australian Spec)
211
4751000
4
Flatwasher #10
212
4751400
4
Flatwasher 1/4in
213
Ref
Harness, Battery Charger Options (See ELECTRICAL SECTION
for Breakdown)
213
4922518
1
USA Built Machines (Prior to SN 0200097450)
213
4922628
1
USA Built Machines (SN 0200097450 through 0200230091)
213
4922628
1
Belgium Built Machines
214
3571584
1
Plate, Plug Inlet
215
4460428
1
Connector, Strain Relief
