SECTION 3 - SCISSORS ARMS
92
3369LE/4069LE/M3369/M4069
3121825
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
39
3422778
2
Pin, Pivot
40
3422822
2
Pin, Pivot
41
3422825
16
Pin, Pivot
42
3422826
4
Pin, Pivot
43
3422905
1
Pin, Pivot
44
3422907
1
Pin, Pivot
45
3450304
4
Pin, Cotter 3/32in x 1in
46
3760387
4
Ring, Retaining
47
3760420
20
Ring, Retaining
48
3841143
2
Keeper, Pin
49
4360500
1
Switch, Rotary Angle Sensor
50
4360502
1
Switch, Proximity Sensor
53
4711400
10
Flatwasher 1/4in Narrow
54
4711500
24
Flatwasher 5/16in Narrow
55
4740332
20
Washer, Special
56
4740480
4
Washer, Plastic Insert
57
4751000
4
Flatwasher #10
58
4751500
4
Flatwasher 5/16in
59
4711600
1
Flatwasher 3/8in Narrow
60
1001099550
2
Slider Weldment (Bottom) (was p/n 4845986 & 4630012)
60A
0440234
4
Bushing (2 Per Assembly)
61
4846020
1
Prop, Safety
62
4922544
1
Harness, Lift Down (Not Shown - See CYLINDER SECTION for
Breakdown)
66
Ref
Bracket/Block Options:
66A
0902703
1
Bracket for USA Built Machines (Prior to SN 0200138293)
66B
0903273
1
Bracket for USA Built Machines (SN 0200138293 through
0200152398)
66C
3200453
1
Block for USA Built Machines (SN 0200138293 through
0200152398)
66D
0902703
1
Bracket for Belgium Built Machines
68
1320122
1
Clamp
69
1320110
1
Clamp, Support
70
1670995
1
Cover, Hose/Cable
73
4280295
6 in/15cm
Strip, Protective
74
0100035
AR
Compound, Locking
75
4922543
1
Harness, Lift Down (Not Shown - See ELECTRICAL SECTION
for Breakdown)
76
3300455
2
Locknut #10-24NC (Stainless Steel)
78
0630550
3
Capscrew 1/4in-20NC x 3/4in
79
4740438
2
Washer, Special
80
3422927
1
Rollpin
81
Ref
Bushing Options:
81
0440234
4
0270853 Installation
81
0440250
4
0272932 Installation
82
0641410
2
Bolt 1/4in-20NC x 1 1/4in
83
4740506
2
Flatwasher #10 (Stainless Steel)
Ref
Arm Kit Options (Include 2-12, 15-16, 19, 33, 37, 54 & 81):
2901930
1
0270853 Installation
2902253
1
0272932 Installation
