SECTION 3 - SCISSORS ARMS
100
3369LE/4069LE/M3369/M4069
3121825
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
41
3422369
1
Pin, Plunger
42
3422778
4
Pin, Pivot
43
3422822
2
Pin, Pivot
44
3422825
24
Pin, Pivot
45
3422826
2
Pin, Pivot
46
3422905
1
Pin, Pivot
47
3422907
1
Pin, Pivot
48
3450304
4
Pin, Cotter 3/32in x 1in
49
3760387
4
Ring, Retaining
50
3760420
26
Ring, Retaining
51
3841143
2
Keeper, Pin
52
4360500
1
Switch, Rotary Angle Sensor
53
4360502
1
Switch, Proximity Sensor
56
4711400
10
Flatwasher 1/4in Narrow
57
4711500
32
Flatwasher 5/16in Narrow
58
4740332
26
Washer, Special
59
4740480
4
Washer, Plastic Insert
60
4751000
8
Flatwasher #10
61
4751500
4
Flatwasher 5/16in
62
4711600
1
Flatwasher 3/8in Narrow
63
1001099550
2
Slider Weldment (Bottom) (was p/n 4845986 & 4630012)
63A
0440234
4
Bushing
64
4846020
1
Prop, Safety
65
4922545
1
Harness, Lift Down (Not Shown - See ELECTRICAL SECTION
for Breakdown)
70
1320122
1
Clamp
71
1320110
1
Clamp, Support
72
1670995
1
Cover, Hose/Cable
75
4280295
6 in/15cm
Strip, Protective
77
Ref
Bracket/Block Options:
77A
0902703
1
Bracket for USA Built Machines (Prior to SN 0200138293)
77B
0903273
1
Bracket for USA Built Machines (SN 0200138293 through
0200152398)
77C
3200453
1
Block for USA Built Machines (SN 0200138293 through
0200152398)
77D
0902703
1
Bracket for All Belgium Built Machines
78
0100035
AR
Compound, Locking
79
4922543
1
Harness, Lift Down (Not Shown - See ELECTRICAL SECTION
for Breakdown)
80
3300455
2
Locknut #10-24NC (Stainless Steel)
82
0630550
3
Capscrew 1/4in-20NC x 3/4in
83
4740438
2
Washer, Special
84
3422927
1
Rollpin
85
Ref
Bushing Options:
85
0440234
4
0270853 Installation
85
0440250
4
0272932 Installation
86
0641410
2
Bolt 1/4in-20NC x 1 1/4in
87
4740506
2
Flatwasher #10 (Stainless Steel)
Ref
Arm Kit Options (Includes 2-15, 17, 18, 28, 35, 57 & 81)
2901931
1
0270854 Installation
2902254
1
0272933 Installation
