Page 26
SECTION 1 - FRAME
26
3369LE/4069LE/M3369/M4069
3121825
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
(Prior to SN 0200141266)
224
See Note
2
Plug (Note: Not Available - Use Slotted Pin in Item 303) (Prior to
SN 0200141266)
224
70003725
2
Pin, Slotted (SN 0200141266 through 0200230091)
Ref
KIT OPTIONS:
Ref
Seal Kit Options:
300
7021333
1
Seal Kit (Includes Items 19-22, 33 & 54)
Ref
Repair Kit Options:
301
7024981
1
Planet Gear Kit 1 (Includes Items 1, 11 & 15)
302
7024986
1
Planet Gear Kit 2 (Includes Items 2, 10,14 & 17)
303
7024047
1
Bearing Kit (Includes Items 4, 12, 19, 20, 23, 33 & 224)
Ref
NOTE: Unless there is capability to torque shaft nut (item
4) to 625 ft/lbs (850Nm) Repair beyond this level is NOT
advised.
304
7021329
1
Cover Kit (Includes Items 8, 21, 22, 33, 34 & 51-54)
305
7021338
1
Mechanical Disconnect Kit 1(Includes Items 54-56, 59 & 66)
306
7024054
1
Mechanical Disconnect Kit 2 (Includes Items 51, 53, 54 & 56)
