SECTION 1 - FRAME
3121825
3369LE/4069LE/M3369/M4069
69
FIGURE 1-19. COVERS INSTALLATION (FRAME MOUNTED)
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
0270740
Ref
FRAME AXLE COVERS INSTALLATION
C
1
0271009
1
Cover Assembly
2
0641408
13
Bolt 1/4in-20NC x 1in
3
1670979
1
Cover
4
1670980
1
Cover
5
Ref
Cover Options:
5
1670981
1
Without Leveling Jacks
5
1671009
1
With Leveling Jacks
6
2080052
8
Fastener, Insert
7
3311405
5
Locknut 1/4in-20NC
8
4060803
AR
Flex-Trim
9
4751400
18
Flatwasher 1/4in Regular
0270576
Ref
ENGINE COVER INSTALLATION (3369LE & 4069LE ONLY)
B
102
0641406
4
Bolt 1/4in-20NC x 3/4in
103
1670990
1
Cover, Front
104
4711400
8
Flatwasher 1/4in Thin
105
3311405
4
Locknut 1/4in-20NC
