SECTION 2 - GROUND CONTROLS
3121825 3369LE/4069LE/M3369/M4069 87
FIGURE 2-6. BATTERY BOX INSTALLATIONS
ITEM PART NUMBER QTY DESCRIPTION REV
Ref BATTERY BOX INSTALLATIONS
0270524 Ref 370A-HR Batteries H
1001104956 Ref 390A-HR AGM Batteries C
1 0100051 AR Grease, Terminal
2 0182017 4 Angle, Battery Hold-Down
3 Ref Battery Options:
3 0400055 8 370A-HR Wet Battery (Standard)
3 7016177 8 370A-HR Dry Battery (Optional)
3 1001102534 8 390A-HR AGM Wet Battery (Standard)
3 Not Available 390A-HR AGM Dry Battery (Optional)
4 0630526 16 Bolt, Special (Used on 370A-HR Batteries Only)
5 0630549 4 Bolt 3/8in-16NC x 1-1/4in
6 0641504 8 Bolt 5/16in -18NC x 1/2in
7 0840048 AR Boot, Terminal - "d" Shaped
8 0840049 AR Boot, Terminal - "b" Shaped
9 0940087 4 Bumper (Used on 370A-HR Batteries Only)
10 1060884 4 Cable, Battery (Battery - to Battery +)
11 Ref Cable, Battery Options (Battery - to Battery +):
11 1060885 2 Cable (with 90 Ring Terminal) (370A-HR Batteries)
11 1060884 2 Cable (390A-HR AGM Batteries)
12 1060886 2 Cable, Battery (Batteries to Anderson Connector)
13 1060887 1 Cable, Battery (Anderson Connector to Contactor)
15 1670972 2 Cover, Battery Box
16 2540038 4 Grommet
17 2940133 2 Latch, Draw
18 3000018 2 Liner, Battery Box
19 3300429 16 Nut, Special
20 4740474 16 Lockwasher, Stainless Steel 5/16in
21 3310801 8 Nut #8-32NC
22 3311401 4 Nut 1/4in-20NC
23 3311505 4 Locknut 5/16in
24 3340903 4 Pad, Slide
25 3900190 4 Screw, Shoulder
27 3900305 8 Screw #8-32NC
28 3931430 4 Capscrew, Socket Head 1/4in-20NC x 1-7/8in
29 4711500 8 Flatwasher 5/16in Narrow
30 4740480 4 Washer, Plastic Insert
34 Ref Battery Box Weldment Options:
34 4846297 2 Box (370A-HR Batteries)
34 1001105085 2 Box (390A-HR AGM Batteries)
35 0100011 AR Compound, Locking
36 1001114496 1 Sensor, Battery Temperature (Machines with Delta-Q Charger)
