SECTION 6 - HYDRAULIC
3121825
3369LE/4069LE/M3369/M4069
151
FIGURE 6-1. HYDRAULIC DIAGRAM - FIXED AXLE
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
Ref
HYDRAULIC DIAGRAMS
2792443
Ref
Hydraulic Diagrams 3369LE & M3369
E
2792445
Ref
Hydraulic Diagrams 4069LE & M4069
F
1
2220415
3
Fitting, Straight
2
2220371
2
Fitting, Straight
3
2220373
1
Fitting, Straight
5
2220504
1
Fitting, Tee
8
2230024
2
Fitting, Bulkhead
9
2221041
1
Fitting, Tee
13
2220466
4
Fitting, 90
18
2752958
1
Hose
20
2752593
1
Hose
21
2752444
1
Hose
22
2750905
1
Hose
24
2752983
2
Hose
28
2753527
1
Hose
29
2753528
1
Hose
32
Ref
Hose Options:
32
2750766
1
Hose 3369LE & M3369
32
2753187
1
Hose 4069LE & M4069
34
2220810
1
Fitting, Straight
35
2220600
1
Fitting, Straight (4069LE & M4069)
36
2220651
1
Fitting, Straight (4069LE & M4069)
37
2221044
1
Fitting, 45 (4069LE & M4069)
38
4640757
1
Valve, Color Flow (4069LE & M4069)
39
4640744
1
Valve, Inline Check
40
2221086
1
Fitting, Nipple
0275481
Ref
HYDRAULIC COMPONENTS FROM ARMS INSTALLATION -
3369LE & M3369
A
134
2220371
1
Fitting, Straight
135
2220473
1
Fitting, 90
136
2753137
1
Hose
137
2753526
1
Hose
0275482
Ref
HYDRAULIC COMPONENTS FROM ARMS INSTALLATION -
4069LE & M4069
A
236
2220371
2
Fitting, Straight
237
2220473
1
Fitting, 90
238
2220635
1
Fitting, Tee
239
2220899
1
Fitting, Tee
240
2753137
1
Hose
241
2753414
1
Hose
242
2753415
1
Hose
243
2753526
1
Hose
