SECTION 5 - CYLINDER
3121825 3369LE/4069LE/M3369/M4069 133
FIGURE 5-3. LEVELING JACK CYLINDER ASSEMBLY (SN 0200104829 through 0200112734, SN
1200000100 through 0200230091)
ITEM PART NUMBER QTY DESCRIPTION REV
1684217 Ref LEVELING JACK CYLINDER ASSEMBLY A
1 0100011 AR Compound, Locking
2 0100035 AR Compound, Locking
6 1120108 1 Cap, End
7 1681283 1 Head
8 1684206 1 Rod, Cylinder
9 1683967 1 Barrel, Cylinder
10 2220883 2 Plug
12 3300465 1 Locknut 1 1/4in-12NC
13 4846584 1 Pad, Jack
14 3480092 1 Piston
15 3573513 1 Plate
18 See Note 1 Ring, Wear (Note: use p/n 2901941)
19 See Note 2 Guidelock (Note: use p/n 2901941)
20 See Note 1 O-Ring (Note: use p/n 2901941)
21 See Note 1 O-Ring (Note: use p/n 2901941)
22 See Note 1 Seal, Wiper (Note: use p/n 2901941)
23 See Note 2 Polyseal (Note: use p/n 2901941)
24 See Note 1 Hydrolock (Note: use p/n 2901941)
26 4640495 1 Valve, Counter Balance
26 2900770 1 Seal Kit - 4640495 Valve
27 4641156 1 Valve, Check
27 2900770 1 Seal Kit - 4641156 Valve
28 3760460 2 Ring, Retaining
29 3900321 3 Screw, Special 1/2in-13NC x 1 1/4
30 4713000 1 Flatwasher 1 1/4in
Ref KIT OPTIONS:
100 2901941 1 Seal Kit (Includes Items 18-24)
